Main Features

• Resolution: 16-bit
• Analog Input Range: ±150mV, ±500mV, ±1V, ±5V, ±10V, ±20mA
• Channel: 6 channel differential/ 2 channel single-ended or 8 channel differential (jumper select)
• Sampling Rate: 10Hz
• With Modbus communication protocol (R-8017+)

Main Specifications

• Interface: RS-485
• Format: N, 8, 1
• Baud Rate: 1200 ~ 115200bps
• 1 LED as Power/Communication indicator
• Power Input: +10 to +30VDC
• Power Consumption: 1.3W
